Location:Home > Products > Ordinary cell > C017 series full quartz-photoelectrochemical cell spectrum electrochemical cell (bottom light)
Related
Introduction
The cell body of electrolytic cell is welded by full quartz fusion method and refuses to stick
The light transmittance of quartz in the electrolytic cell is above 95%
The lid of the electrolytic cell is PTFE
The electrolytic cell can be equipped with a gas inlet and outlet device
The reference electrode of electrolytic cell generally selects a conventional reference electrode with a diameter of 6 mm.
For comparison electrode of the electrolytic cell, electrode with a rod diameter of 6 mm can be selected
The working electrode of the electrolytic cell can be selected from electrode or electrode clamp with a rod diameter of 6mm
The electrolytic cell is relatively sealed
The quartz sealing part of the electrolytic cell is designed with a flange port, and the cover is made of PTFE and the sealing ring is locked by a locking ring to seal.
The electrode part of the electrolytic cell is sealed on the PTFE plug, and the sealing effect is achieved by pressing the O ring with the sealing screw
For absolute sealing system, please refer to C017-2
